FILAMENT WINDING

BYRAJESH KUMAR DWIVEDI
2008AMD3100
Filament winding is a fabrication technique for
forming reinforced plastic parts of high
strength and light weight.
The use of circumferential
increase the bursting strength.
wrapping
to


1.
2.
Precision high-speed positioning of continuous
fiber in a pre-determined pattern is the basis of
the filament winding process .
In this there is a mandrel that the fiber and
resin wound upon, is cured in room temp or in
oven. After cure mandrel is removed leaving a
hallow composite structure.
circular type
rectangular type


Circumferential winding
Helical winding
CuringPolymerization of composites on mandrel.
Pressure chambersSystem also requires pressure in addition to heat.




Epoxy resins
Polyester resins
Phenolic resins
Silicone resins





Fabrication variables
Processing variables
Winding variables
Material's variables
Environmental variables
weathering
humidity
Advantages –
1. a very fast and economic method
2. Structural properties of laminates can be very
good
Limitation –
1. Lack of ductility
2. Low modulus of elasticity




Storage tank
Railway tank car
Pipe
Aerospace
