Air-movement range

A
C
Ø 143
Air-Movement
Ø 1/2 ''
Ø 12.695
Air-movement range
g
n
i
t
a s
r
b
e
Cel 0 year ess
4 usin
in b
rangeperformanceservice
About Us
Royce Cross Agencies prides itself on its large electrical motor and accessory
range, product performance, personalised technical service and speedy delivery
throughout Australia.
Our range of high-quality electric motors includes such brands as the Royce Cross RCG
(which replaces the REMX brand), Crompton Greaves, Toshiba, ABB, Transtecno and
Baldor.
When it comes to electric motors, the team at Royce Cross Agencies offers unparalleled
knowledge and experience. Our resourceful staff assist a vast array of industries, from
agriculture, manufacturing and engineering to electrical, mining, air conditioning and
refrigeration. Our technical team also supplies to individuals with home hobbies.
We deliver nationally with orders normally shipped within one to two days. Royce Cross
Agencies understands individual needs and adapts to customers’ requirements.
Our specialisation in the electric motor business has enabled us to develop and enhance
our business, offering a complete solutions package, which includes:
•
•
•
•
•
•
•
Three-phase motors
Single-phase motors
Air-movement motors
Variable speed drives
Geared motors
DC motors & controllers
Accessories
Technical services
Royce Cross Agencies has established a large network of motor technical
specialists that provide a range of quality services which include:
•
•
•
•
•
•
•
•
Motor rewinds and repairs
Motor redesign and engineering
Motor overhaul
Motor weatherproofing
Mechanical services
Testing
Industrial electronics
Design starter/VSD construction
Visit www.roycecross.com.au to order your products online. Alternatively, speak with a
member of our technical sales team by calling 1300 553 229.
All Royce Cross Agencies (RCA) products are regularly redesigned. RCA reserves the right to modify the design, technical specification and dimensions without prior notice. E&OE.
Contents
RCT Air movement series
1. RCT52 - Fridgemaster series Page 4
2. RCT76 & 82 - General purpose motors
Page 6
3. RCT85 - Totally enclosedcondenser motor
Page 8
Mounting Codes:
M02 - Band Mount
B02 - Resilient Mount - single shaft
F02 - Stud Mount
4. RCT85 - Single-shaft blower motor
Page 10
Mounting Codes:
B02 - Resilient mount - single shaft
5. RCT85 - Double-shaft (ODF) blower motor
Page 12
Mounting Codes:
C02 - Resilient mount - double shaft
6. RCT90 - Double-shaft fan motor
Page 14
Mounting Codes:
C02 - Resilient mount - double shaft
7. Accessories
Page 15
Ph: 1300 553 229
www.roycecross.com.au
RCT52 Fridgemaster series
The RCT52 series has been designed for flexibility of application used mostly in
refrigeration and for small fan uses.
The series offers a more efficient PSC design over shaded pole motors.
Key features
- Thermal fuse
- Efficient PSC design
- Standard shaft and hub drive
- Universal mounting arrangement
- Electrically reversible
- Capacitor supplied
- Mounting screws
supplied
- 12 month warranty
- Distinctive snap and fit four in one design
(40 watt version)
RCG part no
Replaces Fasco/Betts
Replaces Kulthorn
Replaces Brinsmead
RCT52-134S-TE
30D501-80A / 50D501-80A
KL10D / KJB2M4701
BLD13-11A
RCT52-204S-TE
30D502-80A / 50D502-80A
KL20D / KJB2P4700
BLD20-11A
RCT52-404DS-TE
30D503-80A / 50D503-80A
KL40DB / KJF2F4700
BLD40-11A
Motor specifications
RCG Part
no
Watts Full
Speed
out
load RPM
AMPS
Cap.
size
uf/V
Cap.
supplied
Reversible Voltage Suits
fan
dia
Suits
fan
pitch
RCT52-134S-TE
13
0.15
1350
2/440
YES
YES
240
229
40o
RCT52-204S-TE
20
0.25
1300
2/440
YES
YES
240
254
40o
RCT52-404DS-TE
40
0.50
1300
2/440
YES
YES
240
275
40o
Fan selections are based on 5 blade propeller style fans and are a guide only. Check fan curves prior to selecting alternate style fans.
4
Dimensions
RCT52 single shaft (13 & 20 watt)
32 ± 2
70
3 holes
tapped M5x0.8
on PCD 71.4
both ends
45°
± 0.5
Ø 5/16''
Ø 7.924
4 holes
tapped M5x0.8
on PCD 54.0
both ends
( 4 Screw Provided )
12
0°
90.4
110
17.5
RCT52 double shaft (40 watt)
36 ± 2
70
32 ± 2
3 holes
tapped M5x0.8
on PCD 71.4
both ends
45°
± 0.5
4 holes
tapped M5x0.8
on PCD 54.0
both ends
( 4 Screw Provided )
12
0°
Ø 5/16''
Ø 7.924
90.4
110
17.5
98.5± 2
Ph: 1300 553 229
5
RCT76 & 82 General purpose motors
The RCT76 & 82 series has been designed specifically for general purpose application.
Offering flexibility and adaptability the series can be applied to domestic, commercial
and light industrial use. Common applications include cement mixers, drill presses and
light duty machinery.
Key features
- Drip proof air cooled
- 4 pole
- 1 metre flex and plug
- Foot mounted
- Single phase 240V 50Hz
- Electrically reversible
-
RCG part
no
Watts Full
Speed
out
load RPM
AMPS
Standard
rotation
directions
Reversible Voltage Type
S.25C4SRCM
250
3.1
1430
ACW
YES
240
Split Phase
S.37C4CRCM
370
3.7
1430
ACW
YES
240
Cap Start
6
Dimensions
RCT76
Ø 131.5
130± 1
87 ± 1
Switch ON/OFF
With weather proof cover
101± 1
37 ± 0.5
+0
-0.3
Ø 1/2 ”
Ø 12.695
71
+0
-0.03
+0
-0.5
12
56
56
40
45
45
45
110
148
231± 2
RCT82
148± 1
ØØ1
14747
97 ± 1
Switch ON/OFF
With weather proof cover
120± 1
46± 0.5
Ø 5/8 ”
Ø 15.87
+0
-0.03
78
+0
-0.5
14.7
+0
-0.3
62.5
62.5
165
48
50
50
50
130
268± 2
Note: direction of rotation is viewed from shaft end.
Ph: 1300 553 229
7
RCT85 Single-shaft condenser motor
The Totally enclosed RCT85 series motor range is designed for a variety of outdoor
applications, including condensing units and ventilation systems.
The RCT85 series is designed to industry standards which allows them to be directly
interchangeable with existing motors.
Flexibility in the design process enables motors to be manufactured to meet specific
customer designs.
Key features
- Low noise bearings
- Designed to international standards
- Auto reset thermal overload on 1 & 3
phase motors
- Interchangeable with other brands
- Permanent split capacitor design
- Totally enclosed
- 4 and 6 pole
- Dynamically balanced rotors
- Long bearing life
- CE certified
- Design suitable for Triac control, available on
request
Replacement chart
RCG part no
Replaces Kulthorn
RCT85-1804S-TE-M02
808554LTB-A80 / 61S072-15
KHFZF4702
RCT85-1804S-TE-M02T
808534LTB-A12
RCT85-1804S-TE-F02T
8061S107-02
RCT85-1506S-TE-M02
808557KTB-A11 / 61S059-80
HF3G4701K
RCT85-2506S-TE-M02
8061S137-80
KHF3J4702
RCT85-3006S-TE-M02
8061S118-02 / 8061S118-03
RCT85-3706S-TE-M02
8061S120-80
RCT85-2506S-TE-M02T
808536MTB-A11 / 61S124-80
RCT85-3706S-TE-B02T
8061S121-80
RCT85-4254S-TE-B02
8061S079-02
8
HF3Q4700K
Dimensions
RCT85 Total Enclosed
RCT85 Total Enclosed
(Band Mount (MO2) Stud Mount (F02)
Resilient Mount Single Shaft (B02)
A
A
C
D
B
Ø 1/2 ''
Ø 12.695
Ø 1/2''
Ø 12.695
E
B
Ø 143
C
3/8'' BSW x 16 TPI (RH)(4 Off)
RCG part no
Dimension
A
B
C
D
RCT85-1804S-TE-M02
230
103
70
57
RCT85-1804S-TE-M02T
234.5
107
74.5
53
RCT85-1804S-TE-F02T
234.5
107
74.5
53
RCT85-1506S-TE-M02
234
119
62.5
53
RCT85-2506S-TE-M02
258
131
74
53
RCT85-3006S-TE-M02*
209
144
64
N/A
RCT85-3706S-TE-M02
267
144
70.5
53
RCT85-2506S-TE-M02T
253
126
74
53
RCT85-3706S-TE-B02T*
205
131
60
N/A
RCT85-4254S-TE-B02*
229.5
134
80
N/A
E
176
*Motors not fitted with a terminal box
RCG part no
Watts
out
Full
Speed Speed
load RPM
AMPS
Cap.
size
uF/V
Cap.
Standard Reversible
supplied rotation
direction
Voltage Suits
Fan
Dia.
Suits
Fan
Pitch
RCT85-1804S-TE-M02
180
1.25
1380
Single
4/440
YES
CW
YES
240
406
25o
RCT85-1506S-TE-M02
150
1.2
900
Multi
6/440
YES
CW
YES
240
457
40o
RCT85-2506S-TE-M02
250
2.3
910
Single
4/440
YES
ACW
YES
240
508
40o
RCT85-3006S-TE-M02
300
2.7
910
Multi
6/440
YES
CW
YES *
240
559
30o
RCT85-3706S-TE-M02
370
2.9
900
Single
8/440
YES
CW
YES
240
559
35o
RCT85-4254S-TE-B02
425
3.1
1200
Multi
15/440
YES
CW
YES *
240
457
35o
* Can be mechanically reversed with internal modifications
RCG part no
Watts
out
Full
Speed Speed
load RPM
AMPS
Cap.
size
uF/V
Cap.
Standard Reversible
supplied rotation
direction
Voltage Suits
Fan
Dia.
Suits
Fan
Pitch
RCT85-1804S-TE-M02T
180
0.75
1400
Single
NIL
N/A
CW
YES
415
406
25o
RCT85-1804S-TE-F02T
180
0.75
1400
Single
NIL
N/A
CW
YES
415
406
25o
RCT85-2506S-TE-M02T
250
0.95
900
Single
NIL
N/A
CW
YES
415
508
40o
RCT85-3706S-TE-B02T
370
1.1
890
Single
NIL
N/A
CW
YES
415
559
35o
Fan selections are based on 5 blade propeller style fans and are a guide only. Check fan curves prior to selecting alternate style fans.
Note: direction of rotation is viewed from shaft end.
Ph: 1300 553 229
9
RCT85 Single-shaft blower motor
The RCT85 series Single Shaft range of motors have been designed to industry standard
which allows them to be directly interchangeable with existing motors.
They have been designed for a variety of air movement applications, including ducted
heating and evaporative cooling systems.
Motors can be manufactured to customer, specified designs, including low harmonic
variable speed applications.
Key features
- Long bearing life
- Auto reset thermal overload
- 3 speed tapped winding
- Design suitable for Triac control
available on request
- Resilient mount (cradle not supplied)
Replacement chart
RCG part no
Replaces Kulthorn
RCT85-3154S-B02
8061S109-03 / 8061S109-07 / 808555NVA-A13
HF2J4701K
RCT85-5504S-B02
8061S082-03 / 8061S082-17 / 8061S082-24
KHF2T4703
RCT85-7504S-B02
8061S128-02 / 8061S128-06
10
Dimensions
RCT85 Single-shaft
A
C
B
Ø 1/2 ''
Ø 12.695
Ø 143
D
RCG part no
Dimension
A
B
C
D
RCT85-3154S-B02
236
119
101.5
137.50
RCT85-5504S-B02
260
144
101.5
161.5
RCT85-7504S-B02
260
144
101.5
161.5
RCG part no
Watts
out
Full
load
AMPS
High
speed
RPM
Speed
Cap.
size
uF/V
Cap.
supplied
Standard
rotation
direction
Reversible Voltage
RCT85-3154S-ODP-B02
290
2.6
1337
Multi
2/440
NO
CW
YES *
240
RCT85-3154S-ODP-B02
315
2.5
1350
Multi
4/440
YES
CW
YES *
240
RCT85-3154S-ODP-B02
350
2.5
1360
Multi
6/440
NO
CW
YES *
240
RCT85-3154S-ODP-B02
365
2.7
1366
Multi
8/440
NO
CW
YES *
240
RCT85-3154S-ODP-B02
425
3.5
1300
Multi
10/440
NO
CW
YES *
240
RCT85-5504S-ODP-B02
600
4.4
1200
Multi
15/440
YES
CW
YES *
240
RCT85-7504S-ODP-B02
750
4.9
1360
Multi
20/440
YES
CW
YES *
240
Note: Direction of rotation is viewed from shaft end.
All RCT85-3154S-ODP-B02 above models do not come with a capacitor . An extra charge will apply.
* Can be mechanically reversed with internal modifications
Ph: 1300 553 229
11
RCT85 - Double-shaft blower motor
The RCT85 series Double Shaft range includes enhanced efficiency, low temperature rise
and resilient mounting.
The range has been designed to industry standards and allows for interchange with
existing motors as well as design flexibility to incorporate customer, specific designs.
The RCT85 series has been designed for a variety of air movement applications, including
reverse-cycle air-conditioning units and circulation fan systems.
Key features
- 4 and 6 pole
- Auto reset thermal overload
- Long bearing life
- Design suitable for Triac control available on
request
- Resilient mount cradle
- CE Certified
- 3 speed tapped winding
Replacement chart
RCG part no
RCT85-804DS-TE-C02
8061S111-80
RCT85-1004DS-ODP-C02
8061S083-80
8061S122-80
KHF2D4701
8061S019-80
KHF2F4701
8061S109-01, 8061S109-04, 808555NVA-A16, 8061S109-08
HF2J4702K
8061S082-80. 8061S082-15, 808555PVA-A11
HF2T4702K
8061S128-80, 808555QVA-A11
KHF2T4704
RCT85-406DS-TE-C02
8061S134-80
8061S004-80
12
Replaces Kulthorn
Dimensions
RCT85 Double-shaft, resilient mount double-shaft (C02)
B
Ø 14.95
Ø 1/2''
Ø 12.695
84
76.2
170
D
RCG part no
C
+0
-0.1
C
90.0
88.4
Ø 143
A
Dimension
A
B
C
D
RCT85-804DS-TE-C02
458
94
182.5
119
493
93
200
119
450
93
178.5
119
517
99
209
125
555
111
222
135.5
610
136
237
159.5
610
136
237
159.5
RCT85-406DS-TE-C02
610
99
255.5
125
520
111
204.5
135.5
RCG part no
Watts
out
Full
load
AMPS
High
speed
RPM
Speed Cap.
size
uF/V
Cap.
supplied
Standard Reversible Voltage
rotation
direction
RCT85-804DS-TE-C02
80
0.8
1350
Multi
4/440
YES
CW
YES
240
100
1.1
1370
Multi
2/440
YES
ACW
YES
240
130
1.2
1370
Multi
4/440
YES
ACW
YES
240
250
1.8
1300
Multi
6/440
YES
CW
YES
240
290
2.6
1337
Multi
2/440
NO
ACW
YES
240
315
2.5
1350
Multi
4/440
NO
ACW
YES
240
350
2.5
1360
Multi
6/440
NO
ACW
YES
240
365
2.7
1366
Multi
8/440
NO
ACW
YES
240
425
3.5
1300
Multi
10/440
NO
ACW
YES
240
600
4.0
1330
Multi
15/440
YES
ACW
YES
240
750
4.9
1360
Multi
20/440
YES
ACW
YES
240
RCT85-406DS-TE-C02
40
0.5
900
Multi
2/440
YES
CW
YES
240
200
2.0
890
Multi
4/440
YES
ACW
YES
240
Note: direction of rotation is viewed from lead end. ODP = Open Drip Proof, TE = Totally Enclosed
Ph: 1300 553 229
13
RCT90 Double-shaft fan motor
The Double Shaft RCT90 series is designed for high volume air applications and can be
manufactured to meet specific customer needs.
Key features
- Multispeed
- 4 pole
- Resilient mount
Dimensions
RCT90
Resilient Mount Double Shaft (C02)
700± 2
Ø 165
36.5
36.5
277± 1
Ø 16.95
Ø 1/2''
Ø 12.695
89.2 ± 0.8
211.5± 2
21.1
21.1
63.5
123.8
211.5± 2
76.2
170
79
87.3
306
RCG Part No
Watts
out
Full
High
load speed
AMPS RPM
Speed Cap.
size
uF/V
Cap.
Supplied
Standard
rotation
direction
Reversible Voltage
1100
5.4
Multi
YES
ACW
YES
1420
30/440
240
Note: direction of rotation is viewed from lead end.
Replacement chart
RCG part no
809455SVA-B12, 809455SVB-B16
14
Ph: 1300 553 229
Accessories
Accessories available include a range of brackets to provide flexible mounting options,
and rain shields to provide extra protection against water ingress in vertical shaft-up
applications.
Mounting bracket
38
45°
45°
19
15
15
°
RCT85-002
45°
30°
30°
°
45°
42
90°
Ø 12.7 x 4 holes
on PCD 180.6
3/8'' BSW
x 16 TPI (RH)
(4 off)
.5
0°
12
0°
12
45°
94
45°
3/8'' BSW
x 16 TPI (RH)
(3 off)
9
RCT85-004
18
RCT85-003
Ø 12.7 x 3 holes
on PCD 180.6
45°
19
45°
38
19
38
Rain shield
46
RCT85-001
Ø
7
Ø 177
Ø 172
+0
- 0.05
.5
18
Ø 12.6
Ø
17
Ph: 1300 553 229
15
RCG is the Royce Cross Agencies motor brand. The
family-owned company has been in operation for 40
years. The brand represents a long history of delivering
quality products which meet efficiency standards and
quality regulations.
Our air-movement range has been manufactured in a
world-class manufacturing facility that has been
delivering electric motors for more than 16 years.
Re-produced August 2012 V6

Air-movement range

Transcription

Similar documents
